IN.05.501 Free Swing Pivot set Heavy Duty for wooden doors

$1,050.00
/
Tax included.
Weight

Free swing pivot



Mechanical pivot system

501 FREE is a high-capacity mechanical pivot system designed for doors up to 500kg. The pivot mechanism is fully embedded in the door leaf, maintaining clean visual lines with no exposed external elements.

Heavy-duty pivot system for doors weighing up to 500 kg.

Designed to deliver maximum efficiency, the pivot door system combines high load capacity with exceptional performance. Its advanced engineering ensures smooth and seamless opening and closing, providing a refined and quiet user experience.

With precise adjustment features, it allows for fine-tuning during installation to ensure perfect alignment and highly accurate results. Ideal for projects demanding quality, durability, and sophisticated aesthetics.

Pivot features

  • Free swing pivot without opening limit

  • Door weight up to 500kgs

  • Adjustment of position on the upper swing and base

  • Upper pivot with needle bearing

  • Installation of the upper pivot from the top of the door

  • No floor cutting or masonry work required for installation

  • Various bases available for different applications

  • Applicable to single or double-action doors

  • Minimum distance from the axis to the top of the door: 150mm

  • Minimum door thickness: 45mm

  • Door width up to 3000mm

  • Power guide function, to electrify the door




Download JNF Warranty Statement here>



 JNF Hydraulic Pivot 200 Plus

To simplify the selection process, JNF proudly introduces PivotLAB — a digital tool designed to help architects, designers, and technical professionals find the ideal pivot system for every project.

Simple & Intuitive Interface

PivotLAB features a clean, user-friendly interface for quick and intuitive navigation. It streamlines the selection process, helping you find the right solution without complexity.

Features

PivotLAB includes a range of calculation and selection tools, along with access to the full JNF pivot system range. It also allows you to save and organise ongoing projects, making them easy to review and manage.

Check it out

Check out the new PivotLAB selector website here.
